LENSES ALCOM SPORT

Regardless of the horizontal curvature of the frame, the pantoscopic angle, the base curvature of the lenses, the higher or lower diopter, the size of the eyepiece – the user always gets the thinnest and lightest lenses with excellent optical properties.

An advanced calculation system calculates free-form surfaces to compensate for aberrations caused by angled installation of lenses in sport spectacles. This allows users to choose from a wide range of frame types. They  will always get an optimal field of view, without prismatic and swimming effect, no matter the frame shape.



Each lens is unique. Areas are recalculated for each user individually, as with individual progressive glasses. Refraction, interpupillary distance, pantoscopic inclination, horizontal curvature of the glasses and 3D shape of the eyepiece are taken into account

The image is excellent over the entire optical surface. The calculation program provides the optimal area at each point separately, even outside the central area.
We recommend measuring the parameters of the frames on our 3D scanner.
We also offer lenses mounting with our 4-axis CNC machine, which is the only one that enables flawlessmounting in even the most demanding frames.

ADAPTATION WARRANTY
All lenses Magic, Reader, Acomoda, Sport RX are 100% inspected with lens quality analyzer Dual Lens Mapper, that assures highest optical quality.

LENS THINNING WITH TECHNOLOGY LUX

For users with high diopters, we recommend lens thinning with Lux technology, which enables thinning of the peripheral area and a very wide field of view.

Lenses can be thinned by few milimeters.

The peripheral thinned area is moved completely toward the handle and is unobtrusive. The appearance of the lens is seen in the figure, which illustrates a wide field of view.

SPORT LENSES MOUNTING OPTION

MODEL LENSES FOR MOUNTING ADAPTER
RXd 4000 Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
RXd 4001 Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
RXd 4001 planet Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
RXd 4002 Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
RXd 4003 Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
RXd 4003 planet Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
RXd 4004 Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
RXd 4006 Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
RXi 4100 Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* insert
RXi 4101v Sport: Trivex*, Tribrid*, NXT*, 1.5*, 1.6*, 1.67* insert
RXi 4102 Sport: Trivex*, Tribrid*, NXT*, 1.5*, 1.6*, 1.67* insert
MODEL   LENSES FOR MOUNTING ADAPTER
001 XS, S, L trace pro Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* e800 XS, S, L
e002 XS, S, L trace Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* e800 XS, S, L
e003 S, L zolid pro Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67*
e004 S, L zolid Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67*
e005 S, L fusor pro Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67 e801 S, L
e006 S, L fusor Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67 e801 S, L
e007 S, L vizor pro Sport: Trivex*, Tribrid*, NXT, 1.5*, 1.6*, 1.67* e802 S, L
e008 S, L vizor Sport: Trivex*, Tribrid*, NXT, 1.5*, 1.6*, 1.67*  e802 S, L
e009 S, L vizor hr pro Sport: Trivex*, Tribrid*, NXT, 1.5*, 1.6*, 1.67*  e803 S, L
e010 S, L vizor hr Sport: Trivex*, Tribrid*, NXT, 1.5*, 1.6*, 1.67*  e803 S, L
e011 nook Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
e012 epyx-y Sport: Trivex, Tribrid, NXT
e015 epyx-x Sport: Trivex, Tribrid, NXT
e018 basou Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
e019 S, L elate.t Sport: Trivex, Tribrid, NXT
e020 S, L elate.p Sport: Trivex, Tribrid, NXT
e023 S, L elate.o pro Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
e024 S, L elate.o Sport: Trivex, Tribrid, NXT
e026 S, L zcale Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
e030 S, L trace ng pro Sport: Trivex, Tribrid, NXT
e031 S, L trace ng Sport: Trivex, Tribrid, NXT


* mandatory with adapter

MODEL LENSES FOR MOUNTING ADAPTER
a126 evil eye pro Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
a127 evil eye pro Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
a167 evil eye halfrim pro Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a530
a168 evil eye halfrim pro Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a531
a180 evil eye halfrim pro Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a539
a181 evil eye halfrim pro Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a530
a189 tycane pro Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67 a540
a190 tycane pro Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67 a541
a191 tycane Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67 a540
a192 tycane Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67 a541
a193 evil eye evo pro Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a542
a194 evil eye evo pro Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a543
a196 tycan pro outdoor Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67 a540
a197 tycan pro outdoor Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67 a541
a198 evil eye halfrim pro Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a531
a199 evil eye halfrim pro Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a539
a266 evil eye Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
a267 evil eye Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
a402 evil eye halfrim Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a530
a403 evil eye halfrim Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a531
a412 evil eye halfrim Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a539
a418 evil eye evo Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a542
a419 evil eye evo Sport: Trivex, Tribrid, NXT, 1.5*, 1.6*, 1.67* a543

* mandatory with adapter

MODEL LENSES FOR MOUNTING
Flak 2.0 Sport: Trivex, Tribrid, NXT
TwoFace Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Chainlink Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Jupiter Squared Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Jawbone Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Clifden Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Drop Point Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Holbrook Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Ojector Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Turbine Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Valve Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Half Jacket Sport: Trivex, Tribrid, NXT
Fuel Cell Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Racing Jacket Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
MODEL LENSES FOR MOUNTING
Rydon Sport: Trivex, Tribrid, NXT
Magster Sport: Trivex, Tribrid, NXT
Agon Sport: Trivex, Tribrid, NXT
Noyz Sport: Trivex, Tribrid, NXT
Firebolt Sport: Trivex, Tribrid, NXT
Stratfly Sport: Trivex, Tribrid, NXT
Ryzer Sport: Trivex, Tribrid, NXT
Kylix XY Sport: Trivex, Tribrid, NXT
Zyon Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Gozen Sport: Trivex, Tribrid, NXT
Guardyan Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Horus Sport: Trivex, Tribrid, NXT
Swifty Sport: Trivex, Tribrid, NXT
DeeWhy Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Sunflower Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Agent Q Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Magnus Sport: Trivex, Tribrid, NXT
Maya Sport: Trivex, Tribrid, NXT
Keyblade Sport: Trivex, Tribrid, NXT
Propulse Sport: Trivex, Tribrid, NXT
Spinair Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Deltabeat Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Guardyan Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Proflow Sport: Trivex, Tribrid, NXT
MODEL LENSES FOR MOUNTING
Anaconda Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Barracuda Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Bounty Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Cervin Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Cobra Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Copperhead Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Crown Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Diablo Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Ecrins Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Fang Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Grace Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
King Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Ouray Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Prince Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Python Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Recoil Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Sarah Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Smart Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Tetra Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
MODEL LENSES FOR MOUNTING
S’Track L Sport: Trivex, Tribrid, NXT
S’Track M Sport: Trivex, Tribrid, NXT
S’Pring Sport: Trivex, Tribrid
Empire Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
MODEL LENSES FOR MOUNTING
Adrenaline Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Essential Endeavor Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Rabid Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Tailwind Sport: Trivex, Tribrid, NXT
Premier Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67
Aero Swift Sport: Trivex, Tribrid, NXT, 1.5, 1.6, 1.67

LENS DIAMETERS REGARDING INDIVIDUAL MATERIAL AND BASE

Material    Base 0 1 2 3 4 5 6 7 8
1.50 75 75 75 75 80 80 80 85* 85*
1.50 Transitions 77   77   77 77 77 77 72
1.50 Polar 76 76 76 76 76 76 80 76 80
1.50 DriveWear     74   74 74 74   74
1.50 BlueViolet Blocker 75 75 75 75 75 75 75 75 75
1.53 Trivex 76 76 76 76 76 76 76 76 76
1.53 Trivex Transitions 76 76 76 76 76 76 76 76 76
1.53 NXT Fixed colour         75   80   80
1.53 NXT Polar         75   75   75
1.53 NXT Varia         75   80   80
1.61 73 73 73 73 73 73 73 73 73
1.61 Transitions 73 73 73 73 73 73 73 73 73
1.61 Polar 73 73 73 73 73 73 73 73 73
1.61 BlueViolet Blocker 75 75 75 75 75 75 75 75 75
1.67 75 75 75 75 75 75 80 80 80
1.67 Transitions 74 74 74 74 74 74 80 74 80
1.67 Polar 73 73 73 73 73 73 80 73 80
1.67 BlueViolet Blocker 75 75 75 75 75 75 75 75 75

All lenses can be decentered up to 10 mm horizontally and vertically.

* anti-reflective or mirror coating is not possible on lenses where the diameter is greater than 80mm.

Fast and simple ordering with application AlcomOnline.
